| Model |
LEF-12i |
| Printing technology |
Piezoelectric inkjet |
| Media |
Width |
Max. 335 mm (13.2 in.) |
| Length |
Max. 310 mm (12.2 in.) |
| Height |
Max. 100 mm (3.94 in.) |
| Weight |
Max. 5 kg (11 lb.) |
| Printing width |
Max. 305 mm (12 in.) |
| Printing length |
Max. 280 mm (11 in.) |
| Ink |
Type |
ECO-UV (EUV, EUV4) 220 cc cartridge |
| Colours |
6 colours (Cyan, Magenta, Yellow, Black, White, Gloss) |
| Ink-curing unit |
UV-LED lamp |
| Print resolution (dots per inch) |
Max. 1440 dpi |
| Distance accuracy*1 |
Error of less than ±0.3% of distance travelled, or ±0.3 mm (±11.8 mil), whichever is greater |
| Connectivity |
Ethernet (10Base-T/100Base-TX, automatic switching) |
| Power-saving function |
Automatic sleep feature |
| Power requirements |
AC 100 to 240 V ±10%, 1.8 A, 50/60 Hz |
| Power consumption |
During operation |
Approx. 156 W |
| Sleep mode |
Approx. 16.7 W |
| Acoustic noise level |
During operation |
60 dB (A) or less |
| During standby |
49 dB (A) or less |
| Dimensions |
999 (W) x 862 (D) x 549 (H) mm (39.3 x 33.9 x 21.7 in.) |
| Weight |
85 kg (187.4 lb) |
| Environment |
Power on*2 |
Temperature: 20 to 32°C (68 to 90°F) (22°C/72°F or higher recommended)
Humidity: 35 to 80% RH (no condensation) |
| Power off |
Temperature: 5 to 40°C (41 to 104°F)
Humidity: 20 to 80% RH (no condensation) |
| Included items |
Roland VersaWorks 6 RIP Software, User’s Manual, adhesive sheet, power cable etc. |
*1 Temperature: 25°C (77°F), humidity: 50%.
*2 Operating environment
Specifications, designs and dimensions listed may be subject to change without notice.
| VersaWorks 6 System Requirements |
| Operating System |
Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit) |
| Hard-disk file system |
NTFS Format |
| CPU |
Intel Core™ 2 Duo, 2.0 GHz or faster recommended |
| RAM |
2GB or more recommended |
| Video card and monitor |
A resolution of 1280 x 1024 or more recommended |
| Free hard disk space |
40 GB or more recommended |
| Optical drive |
DVD-ROM |
| Ethernet Connection |
100 mbps |
| Other |
Internet connection recommended |
